Technical Parameters | 12×4000 | 16×3200 | 20×2500 | 25×2000 | 32×4000 | 40×3200 | 45×2500 | 50×2000 | 20×2500 | 25×2000 | 32×2500 |
Max. rolling width(mm) | 4000 | 3200 | 2500 | 2000 | 4000 | 3200 | 2500 | 2000 | 2500 | 2000 | 2500 |
Max. rolling thickness(mm) | 12 | 16 | 20 | 25 | 32 | 40 | 45 | 50 | 20 | 25 | 35 |
Max. prebending thickness(mm) | 8 | 21 | 16 | 20 | 25 | 32 | 40 | 42 | 16 | 20 | 30 |
Min. rolling diameter(mm) | 800 | 800 | 800 | 800 | 1300 | 1300 | 1300 | 1300 | 800 | 800 | 1000 |
Plate yield limit (Mpa) | 275 | 275 | 275 | 275 | 245 | 245 | 245 | 245 | 245 | 245 | 245 |
Up-roll diameter (mm) | 380 | 380 | 380 | 380 | 650 | 650 | 650 | 650 | 400 | 400 | 560 |
Down-roll diameter(mm) | 340 | 340 | 340 | 340 | 580 | 580 | 580 | 580 | 380 | 380 | 540 |
Side roll diameter (mm) | 280 | 280 | 280 | 280 | 480 | 480 | 480 | 480 | 320 | 320 | 400 |
Plate rolling speed(mm) | 4 | 4 | 5 | 5 | 4.5 | 4.5 | 4.5 | 4.5 | 5 | 5 | 4.5 |
Operating pressure of hydraulic system(Mpa) | 16 | 16 | 20 | 20 | 16 | 16 | 16 | 16 | 12 | 12 | 15 |
Power of main motor (kw) | 30 | 30 | 30 | 30 | 45 | 45 | 45 | 45 | 30 | 30 | 45 |
Overall dimensions (L×W×H) (m) | 7.6× 2× 2.15 | 6.8× 2×2.15 | 5.68× 2.38× 3.67 | 5.56× 2× 2.2 | | 11.5× 2.9× 3.33 | 10.8× 2.9× 3.33 | 10.3× 2.9× 3.33 | 6.06× 2× 2.2 | 5.56× 2× 2.2 | 6.5× 2.76× 3.15 |
