| Quantity: | |
|---|---|
| No. | Name | Parameter | Unit | |
| 1 | Max. Rotary distance | 5000 | N.m | |
| 2 | Max. Bend OD | Φ38*4 | mm | |
| 3 | Min. Bend OD | Φ5 | mm | |
| 4 | Max. Bend radius | R200 | mm | |
| 5 | Min. Bend radius | R20 | mm | |
| 6 | Max. Bend angle | 195 | ° | |
| 7 | Feeding trolley follower stroke | 6000 | mm | |
| 8 | Pipe end min. length | 300 | mm | |
| 9 | Mold center height | 40 | mm | |
| 10 | Machine working height | 1100 | mm | |
| 11 | Bend speed C shaft | 0-5 | r/min. | |
| 12 | Clamping set speed B shaft | 0-10 | r/min. | |
| 13 | Feeding trolley walking speed Y shaft | 0-30 | m/min. | |
| 14 | Speed series | variable speed | | |
| 15 | Repeat precision | C shaft | +/-0.1 | ° |
| Y shaft | +/-0.1 | mm | ||
| B shaft | +/-0.1 | ° | ||
| 16 | Angle pre-set | 99 | type | |
| 17 | Stop(plug) torque | 5000 | N*m | |
| 18 | Motor total power | 7.5 | kw | |
| 19 | Hydraulic system working pressure | <=10 | MPA | |
| 20 | Fuel tank capacity | 1000 | L | |
