| No. | Name | Parameter | Unit | |
| 1 | Max. Rotary distance | 30000 | N | |
| 2 | Max. Bend OD*WT | Φ76*6 | mm | |
| 3 | Min. Bend OD | Φ10 | mm | |
| 4 | Max. Bend radius | R450 | mm | |
| 5 | Min. Bend radius | R40 | mm | |
| 6 | Max. Bend angle | 195 | ° | |
| 7 | Feeding trolley follower stroke | 6000 | mm | |
| 8 | Pipe end min. length | 300 | mm | |
| 9 | Mold center height | 60 | mm | |
| 10 | Machine working height | 1500 | mm | |
| 11 | Bend speed C shaft | 0-5 | r/min. | |
| 12 | Clamping set speed B shaft | 0-10 | r/min. | |
| 13 | Feeding trolley walking speed Y shaft | 0-30 | m/min. | |
| 14 | Speed series | Continuously variable speed regulation | | |
| 15 | Repeat precision | C shaft | +/-0.1 | ° |
| Y shaft | +/-0.1 | mm | ||
| B shaft | +/-0.1 | ° | ||
| 16 | Angle preset | 50 | types | |
| 17 | Stop(plug) torque | 25000 | N*m | |
| 18 | Motor total power | 11 | kw | |
| 19 | Hydraulic system working pressure | <=12 | MPA | |
| 20 | Fuel tank capacity | 3000 | L | |
| 21 | Size | 7*1.6*1.5 | m | |
